American Precision Arms
American Precision Arms is very excited to share the release of the Generation 3 Fat Bastard. It has been a long time coming but we wanted to make sure everything was perfect before offering something new.
The development of APA Gen 3 Fat Bastard was the result of American Precision Arms' constant pursuit of breaking the mold and a desire to meet the demands of the Long-Range and Hunting markets. APA has combined the standards of high-level performance and reliability with distinctive design enhancements to improve both accuracy and performance. These enhancements benefit the shooter experience at the range and in the field where every advantage matters.
The roots of the new Generation 3 version of the Fat Bastard lie in the requests of the elite long-range precision rifle community. APA's goal was to meet the needs of those shooters while also maintaining their standards of pristine manufacturing. Among the design, changes are three key features. The advanced Unique Recoil Profile tunable top port design allows the shooter to fine-tune the muzzle movement for absolute target retention. In addition to that, the new lock nut design creates a zero overrotating platform. Last, is the addition of a fifth Bastard port section that eliminates even more recoil than before.
NOT JUST STOPING RECOIL, BUT LATERAL MOVEMENT AND MUZZLE RISE AS WELL, FOR A TRULY NEUTRAL SIGHT PICTURE.
URP (Unique Recoil Profile) Top Ports
We developed the U.R.P. Adjustable Gas System. These aren't just randomly placed top ports. Every port is placed adjacent to the internal Bastard tooth where there is maximum pressure build-up. This makes the adjustable ports directionally effective.
The unique tunable gas system combined with the trademark APA ports work together to achieve a sight picture that moves less than ever before. There are 10 directional gas ports that can be tuned to counteract you’re U.R.P. (unique recoil profile).
There are endless combinations to keep your sights on target. To calibrate the brake to your U.R.P., start testing with all the gas screws installed. Pay attention to the movement of your reticle, and begin removing the gas screws as the recoil requires.
When the gas screws are removed on the right side, the rifle will be shifted left. For the opposite effect simply remove the screws on the left. The gas holes closer to the nut have a more dramatic effect and the ports closer to the brake crown have a lesser effect. When you find your U.R.P. combination, Threadtite your screws into place.
1.10" in Diameter, 3.5" In Length and Weighs 7.2 oz
Made for a barrel diameters of .850 or larger.
The Gen 3 Fat Bastard can handle magnum cartridges.
Available in 6mm, 6.5mm, .308 (7mm) & .338.
Available in 5/8X24, 3/4x24, 18x1 & 18x1.5 thread patterns.
Each brake includes set screws, one Allen wrench, and a single-use Threadtite.
